Purpose

Wavy edge conveyor belts are widely used in ports, metallurgy, mining, power, coal, casting, building materials, grain, chemical industry and other fields for material conveying. They can convey various bulk materials at any inclination angle of 0-90 degrees continuously. They feature a large conveying inclination, wide range of applications, small footprint, no transfer points, reduced civil engineering investment, low maintenance costs, and large conveying capacity. They solve the problem of conveying angles that cannot be achieved with ordinary conveyor belts or patterned conveyor belts. Wavy edge conveyor belts can be designed as a complete conveying system according to requirements, avoiding the complexity of intermittent conveying and complex conveying lifting systems.

Wavy edge conveyor belts can convey various bulk materials horizontally, inclined, vertically, and at variable angles, ranging from coal, ore, and sand to fertilizers and grains. The material particle size is unlimited, ranging from very small to 400 mm large particles, and the conveying capacity can range from 1 cubic meter/hour to 6000 cubic meters/hour.

Parameters

Base belt width B	Sidewall height	Cross-partition height H1	Wave bottom width B1	Effective belt width B2	Empty edge width B3	Cross-partition shape
300	40	35	25	180	35	TC
	60	55	50	120	40
	80	75
400	60	55	50	180	60	TC
	80	75
	100	90
500	80	75	50	250	75	TC
	100	90
	120	110
650	100	90	50	350	100	TC
	120	110
	160	140	75	300
800	120	110	50	460	120	TC
	160	140	75	410
	200	180
1000	160	140	75	550		TC
	200	180
	240	220
1200	160	140	75	690	180	TC
	200	180
	240	220
	300	260	100	640
1400	200	180	75	83	210	TC
	240	220
	300	260	100	780
	400	360

Introduce

Specializing in the production of various conveyor belts, conveying machinery, and accessories, the company is committed to delivering efficient and reliable material handling solutions to global customers. Its products are widely used in industries such as metallurgy, mining, building materials, power generation, chemical, ports, and grain, helping enterprises achieve automated and intelligent production processes.

Customized Process

Order Notes

To meet diverse industry needs, our products are categorized into multiple specifications based on material handling requirements and operational environments:Standard, Heat-Resistant, Acid/Alkali-Resistant, Oil-Resistant, Cold-Resistant, and Flame-Retardant types.

Goods will be strictly tested before delivery, please check carefully after receiving the goods, if there is any problem, please contact us in time.

Online communication

Provide custom drawings

Merchant quotation

Sign a contract

Processing and production

Packaging and distribution

Confirm receipt of goods

Successful transaction

FAQ

Can you accept small quantities?

Yes, accept small quantity, fast delivery

Do you have pre-shipment inspection procedures?

Yes, we always test the products before delivery.

Can I take samples for testing?

Yes, samples can be sent for testing before bulk ordering.

When is the delivery time?

Inventory orders within 7-15 days, for oem and odm orders, the specific time depends on the actual situation.

What are the terms of payment?

Wire transfer or letter of credit, Western Union, Alipay, etc.

What is the minimum order quantity?

It depends on the product.
